Quick Details

  • Condition: New
  • Type: Piston
  • Configuration: Stationary
  • Power Source: AC Power
  • Lubrication Style: Lubricated
  • Mute: No
  • Place of Origin: Jiangsu, China (Mainland)
  • Brand Name: Yuda
  • Model Number: H1531B
  • Voltage: 380V(It can be made by customer's requirement)
  • Dimension(L*W*H): 1160*810*1600mm
  • Weight: 450-510kg
  • Certification: CE;GC;IAF;ISO9001:2000
  • Warranty: 1 year
  • After-sales Service Provided: Engineers available to service machinery overseas
  • Keyword: 30 bar high pressure air compressor
  • motor: Siemens
  • color: black
  • Cooling type: Air cooling
  • technology: from American
  • Electric parts: Schneider
  • Working pressure: 30bar
  • customization: Can be customized
  • Power: 7.5-30KW
  • Air capacity: 0.7-4M3/min

Packaging & Delivery

Packaging Details: Standard Wooden Case
Delivery Detail: 15 working days

High pressure paintball mini 260 500 psi 30 bar air compressor with good price

Product Description

1, cast iron structure: The air cylinder and the crank case use 100% cast iron material, guarantees the unit the service life.
2, air cylinder: The deep wing piece type, the independent casting air cylinder may 360 degrees eliminations produce compressed air quantity of heat. Between the air cylinder and the crank case with the bold fastening, is advantageous for the routine maintenance and the maintenance.
3, offcenter unloading gear: Release from cold and in air cylinder's air, prevents the unit overload start.
4, adjusting device: All high-pressured unit disposes the automatic start/engine off control, moreover may choose the constant speed control and the dual controls.
5, self-refrigeration draindown system: The self-refrigeration wash water valve installs on the exhaust separator/valve's support, when the compressor engine off or unloads when the constant speed control mode, discharges the condensed water automatically.
9th, electrical machinery: TEFC, the IP54 electrical machinery, conforms to the IEC standard.
6, actuation: The entire seal shroud “V” the belt transmission, the movement is steady.
7, foundation: On the Chungking Steel Works structure's foundation opens has the groove, the electrical machinery may move, is advantageous for the fastening “V” the leather belt.

Technical parameters
High pressure paintball mini 260 500 psi 30 bar air compressor with good price
30bar air compressor
Model
Host Model
Air capacity
(Nm3/min)
Working pressure(Mpa)
Power(KW)
speed(r.p.m)
35VH-0.7/30A-SB
H0621A
0.7
3.0
7.5
680
35VH-0.7/30A(with tank)
0.7
3.0
7.5
680
36WH-1.0/30C-SB




H1231C
1.0
3.0
11
620
36WH-1.2/30C-SB
1.2
3.0
15
760
36WH-1.0/30C(with tank)
1.0
3.0
11
620
36WH-1.2/30C(with tank)
1.2
3.0
15
760
2-36WH-2.0/30C
2.0
3.0
2×11
620
2-36WH-2.4/30C
2.4
3.0
2×15
760
33WH-1.6/30A(Horizontal)
H1531A
1.6
3.0
18.5
790
33WH-1.6/30B(Vertical)
H1531B
1.6
3.0
18.5
790
2-33WH-3.2/30B
3.2
3.0
2×18.5
790
24WH-2.0/30A


H1631A
2.0
3.0
22
735
2-24WH-4.0/30A
4.0
3.0
2×22
735
3-24WH-6.0/30A
6.0
3.0
3×22
735



Products Details

Air Compressor System Connection Diagram

Packaging & Shipping



Our Certificate



Our clients
About us

 Our Factory

Our company

Hengda air compressors are widely use in most chinese manufacturing industries. With perpetual research and development,we in hengda has maintained superior product quality and hence provide highly reliable machine operating performance.
In the pet blow moulding industry, Hengda is the main provider of high quality high pressure air compressors. Having been supplying high pressure compressors to the pet industry for a number of years,we are very familiar with the stringent requirement of the quality of the air requirement.
Being provided with clean and oil-free compressed air is very important. The high pressure air compressors,filters,dryers and control system are specially designed to meet your strict requirement in order to produce high quality pet products.
For international market,we have qualified and well experienced engineers basing in Singapore who provide designing,commissioning and service. all these engineers could give prompt and direct service in your country by the developed airport transportation without andy visa restriction.
