cheap price 20 50 120 150 200 250 ton eva foam injection blow molding machine

FOB Reference Price:Get Latest Price
$28,000.00 - $75,000.00 / Set | 1 Set/Sets 150ton eva foam cheap injection molding machine (Min. Order)
Model Number:
FG40/50/60/80/90
Shipping:
Support Sea freight
Lead Time:
Quantity(Sets) 1 - 1 >1
Est. Time(days) 45 Negotiable
Customization:
Customized logo (Min. Order: 1 Sets)
Customized packaging (Min. Order: 1 Sets)

More

Graphic customization (Min. Order: 1 Sets) Less
Report Suspicious Activity
Overview
Quick Details
Style:
Horizontal
Condition:
New
Plastic Type:
Thermoplastic
Clamping Force:
1180KN
Type:
Injection Blow Molding
Place of Origin:
Jiangsu, China
Brand Name:
Faygo
Automatic:
Yes
Certification:
CE ISO9001
Name:
150ton eva foam cheap injection molding machine
Color:
customer oriented
Voltage:
380V/ 50Hz 3P+N+E (alterable)
Warranty:
12 Months
suitable bottle size:
5ml-1000ml
product max length:
220mm
product max diameter:
120mm
cooling water pressure:
0.3-0.4Mpa
air compressor:
0.7-1.2Mpa
system pressure:
14Mpa
After-sales Service Provided:
Engineers available to service machinery overseas
Injection Weight:
300g/s ~ 1500g/s
Injection Rate:
300g/s ~ 1200g/s
Opening Stroke:
700mm
Power(W):
30KW
Supply Ability
Supply Ability:
38 Set/Sets per Year 150ton eva foam cheap injection molding machine
Packaging & Delivery
Packaging Details
covered by PE film or by wooden box
Port
Shanghai Port
Lead Time :
Quantity(Sets) 1 - 1 >1
Est. Time(days) 45 To be negotiated

cheap price 20 50 120 150 200 250 ton eva foam injection blow molding machine

Product Description

 Advantages of FG series:

1. Down-setting the clamping cylinder ensures the surface clean of the products. The mold chucking force is kept balance and uniform.

2. Decreasing the machine height ensures the easy operation of mold installation

3. Particular Hydraulic servo system and reasonable layout of the pipeline to keep the machine running highly efficient and energy-saving.

4. Particular pressure clamping structure increase the clamping force and reduce the energy consumption of the system.

5. Servo rotary system or high precision indexing device highly increaes the rotary precision and reduce the dry cycle time.

6. Optimized internal rack layout keeps the maintenance more convenient.

Technical parameters



Name
Unit
FG40
FG60
FG80
FG100
Screw diameter
mm
40
45
50/55
60
L/D Ratio

22:1
22:1
22:1
22:1
Injection Capacity
9
176
260
314
415
Heating power
KW
7.5
10
10.8
12
Heating section

3+N
3+N
4+N
4+N
Injection mould clamping force
KN
400
600
800
1000
The injection mold opening stroke
mm
140
140
140
150
Mould clamping force
KN
60
100
120
150
Blow mold opening stroke
mm
140
140
140
150
Injection stroke
mm
160
160
160
160
Mold Size
mm
480*340
600*390
800*400
1000*460
Min. Thickness of Mold
mm
180
240
280
280
Main motor power
KW
11
18.5
22
30
Reject Stroke
mm
210
230
230
230
Dry Cycle Time
s
3.5
4
4
4
Total power
KW
20
30
40
45
Operating power
%
52-70
52-70
52-70
52-70
System pressure
Map
14
14
14
14
Compressed air pressure
MPa
0.7-1.2
0.7-1.2
0.7-1.2
0.7-1.2
Cooling water pressure
MPa
0.3-0.4
0.3-0.4
0.3-0.4
0.3-0.4
Product maximum diameter
mm
120
120
120
120
Product maximum length
mm
200
220
220
220
Product volume
ml
3-800
3-800
3-1000
3-1000
Dimensions
M
3*1.3*1.7
3.5*1.4*1.8
4*1.6*2
4.5*1.8*2
Equipment weight
Ton
3.5
5
8
10
Products details

 Characteristics of FG series machine

Products size

Bottle Size

1.Volume:5ML-1000ML

2.Neck Dia:10-45MM

3.Height:35-200MM

4.Body Dia:45-90MM

Packaging & Shipping
Our Certificate



Our clients
Company Information

Idea:
Abide by the logos of “Sincerity, Development, innovation, Win-Win” constantly, we are honorable to cooperate with friends at home and abroad by providing the high quality products, technology and service!

Market:
Our products have been exported to Middle East, Southeast Asia, South America and Europe etc. We received the universal confirmation and trust from our customers except of the precious experience.

Transportation:
It is located in the beautiful port city of Zhangjiagang with convenient traffic; it’s about 150 km away from Shanghai.
